VEC221E: Designing a SOM with an Intel ARM SoC Fpga

Fpga training series

The Intel® ARM SOC course is composed of two sessions, the first is mainly dedicated to the hardware, the second one will explore the software aspects paying special attention to the OS boot process, including also linux boot.

VEC2210E, hardware session. In this Fpga training you’ll learn to design for a system containing the ARM® Cortex-A9 Hard Processor System (HPS) on Cyclone® and  Arria® SoCs. This course focuses on the hardware aspects of designing the SoC system & includes hands-on labs to get you up & running quickly.
Learn to add & configure the processor component into a Qsys system. You’ll perform debug of the hardware system using standard debug tools such as SignalTap II logic analyzer & System Console.
We’ll discuss hardware to software files handoff that simplifies aspects of software development. You’ll perform low-level debug of the FPGA interacting with the software debugger.
We’ll also discuss various ways the FPGA & HPS components can be loaded & booted. At completion, you’ll be able to use the SoC device in your own design.

At Course Completion you will be able to:

• Create, manage, and compile an SoC based FPGA in the Qsys tool
• Simulate the HPS interfaces using Qsys testbench and simulation model generation features
• Bring up and debug an SoC with the System Console tool
• Explain the hardware to software file handoff
• Design and debug with a Cyclone V based development kit

VEC2211E: This FPGA course is for firmware and low-level software engineers and is intended to teach you about software bring-up and development on the embedded ARM® Cortex-A9 hard processor system (HPS) in an SoC
The course isn’t intended to teach you software application or driver development, but rather concentrates on the unique aspects of the embedded HPS software flow in an Intel® ARM®-SoC.
You’ll learn everything needed to get started developing software for the HPS system, where to go for additional help, as well as how to use the Intel® (Altera®) edition of the ARM DS-5 software development tool to debug your software.

At Course Completion you will be able to:

• Explain the hardware-to-software file handoff
• Explain the stages in the HPS boot sequence & the boot scenarios
• Create the second-state bootloader
• Write bare-metal applications using Intel®’s Hardware Libraries
• Get started with a variety of OSs for the ARM processor
• Get support from the community portal on Linux development
• Use DS-5 development studio to perform FPGA-adaptive software debug

Prerequisites and Skills Required:

• CCompletition of the training VEC110, System Integration with Qsys
• FPGA knowledge is not required, but a plus
• Some basic software knowledge and C/C++ coding skills are required
